Area of Applications:
Water transfer for Apartments, bungalows, farm-houses, building construction, gardening, fountains, overhead storage tanks, pressure booster systems, hotels, hospitals, industrial water circulation
Capacitor Run:
10 micro F
Direction of Rotating:
Anti-clockwise when viewed from driving end
Discharge Range:
1600-270 LPH
Dynamically Balanced Rotor:
Yes
High Suction with Self Priming:
Upto 8 m
Low Power Consumption:
Yes
Maximum Working Pressure:
3 Kg /cm2
Motor Body:
High-quality aluminium die casting
Motor Insulation Class:
Class F
Motor Stator:
Low watt loss silicon steel lamination
Operating Water Temperature:
Upto 65 Degree C
Package Contents:
1 N pump set, 1 N power cord of 1 m length, 1 N instruction manual, 1 N warranty card
Pump Casing:
Graded Cast iron
Shaft:
Stainless steel (SS-410)
Suitable for:
Single phase supply
Voltage Operating Range:
180-240 V
Winding Type:
Copper Winding
