The Groz - 1:6.5, 1500Nm Torque Multiplier is a heavy-duty torque multiplier from Groz. The 1500Nm torque multiplier provides a mechanical advantage for high torque for tightening nuts and bolts. The torque multiplier comes with a chromium-vanadium body with chromium molybdenum square drive and reaction bar. The planetary gear train mechanism of the 1500Nm torque multiplier multiplies the input torque as per the multiplication factor to deliver the output torque. As a result, the operator efforts of the Groz - 1:6.5, 1500Nm Torque Multiplier are considerably reduced by 75% by the multiplicative torque factor. The torque multiplier also includes a breakaway adaptor to prevent damage to the multiplier.
Product Specifications:
Brand: Groz
Maximum input torque: 231 Nm
Maximum torque: 1500 Nm
Torque ratio: 1:6.5
Gear ratio: 1:9
Input drive: 1/2 inches
Output drive: 3/4 inches
Body material: Chromium vanadium
Model: TQM/1-2/3-4/15
Product: Torque multiplier
Country of origin: India
Key Features:
Fit for high torque application.
Torque multiplicative factor reduces operator effort by upto 75%.
Planetary gear train mechanism.
It comes complete with a straight reaction bar, breakaway adaptor, and hex key in a blow moulded case.
