Buy {[en]:GIC SM800 - 145 to 500 VAC, SPP Selectable Under/Over Voltage With Neutral Loss Monitoring Device (DMS110) Online
GIC

GIC SM800 - 145 to 500 VAC, SPP Selectable Under/Over Voltage With Neutral Loss Monitoring Device (DMS110)


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081
GIC

GIC SM800 - 145 to 500 VAC, SPP Selectable Under/Over Voltage With Neutral Loss Monitoring Device (DMS110)

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 1-2 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description
  • LCD Display with Green backlight
  • Multi-Voltage: Three Phase 4 Wire and Three Phase 3 Wire at 145-500 VAC
  • Protection against Phase loss, Phase Sequence,Phase Asymmetry, Under Voltage, Over Voltage, Neutral Open, Over Frequency and Under Frequency
  • Can be configured for 3 Phase 3 Wire or 3 Phase 4 Wire system
  • Selectable Over Voltage/ Under Voltage, Asymmetry,
  • Phase Loss, Phase Sequence, Over Frequency/Under Frequency
  • Adjustable ON/OFF Time Delay in seconds/minutes
  • 5A Single and Dual relay outputs
  • Two Separate Relay outputs with independent Programming
  • Password protection
  • Log of 5 previous faults for better monitoring
  • Fail safe/ Non-Fail safe relay output
  • Latch (Manual) and Non-Latch (Auto) Modes
Product Specifications

GENERAL

Brand:
GIC
Catalog Number:
DMS110
Contact Arrangements:
1 C/O
Country of Origin:
India
Degree of Protection:
IP20 for Enclosure and Terminals, IP40 With Front Facia For Dust cover
Humidity:
95 Percent Rh
Model Number:
SM800
Mounting:
Base/DIN Rail
Output:
Relay Output - 1 C/O, Contact Rating - 5A
Phase Asymmetry:
Voltage 5 to 99 VAC, Default
Power Consumption:
5 VA
Product Type:
SPP Selectable Under/Over Voltage With Neutral Loss Monitoring Device
Supply Voltage:
145 to 500 VAC (3 Phase, 3 Wire, 4W), 45 to 65 Hz
Temperature:
Operating: -10 to +60 Degree C, Storage: -20 to 70 Degree C
Time Delay:
ON Delay 0s to 999s, OFF Delay 0.1s to 999, ON Delay 0.5 to 999s
