Description

The G-Tech - Digital Insulation Tester employs a high voltage, low current DC charge to measure resistance within wires and motor windings to detect current leakage and poor or damaged insulation. The Digital Insulation Tester has a plastic body which is impact-proof. The Insulation Tester shows an analogue bar, real-time reading, a low battery warning, and a faulty fuse warning. The G-Tech - Digital Insulation Tester cover protects against drops and is durable enough for regular use. The Digital Insulation Tester detects voltage, resistance, continuity, current, capacitance, frequency, diode, and battery. The Insulation Tester is highly accurate.
Product Specifications:
Brand: G-Tech
Model: GT-9510
Country: China
Data hold: Yes
DC current: 20 mA-400 mA, +/-1%
DC voltage: 400 mV-4 V-40 V-400 V-1000 V, +/-0.5%
Dimensions: 200x70x70 mm
Product: Digital Insulation Tester
Key Features:
Lightweight
Durable
Protect Against Drops
Detects Voltage
Long-lasting
Accurate Results

Product Specifications

GENERAL

AC current:
20 mA-400 mA, +/-0.8%
AC voltage:
400 mV-4 V-40 V-400 V-700 V, +/-0.8%
Brand:
G-Tech
Capacitance:
40 nF-400 nF-4 ?F-40 ?F, +/-3%
Country of Origin:
China
Data hold:
Yes
DC current:
20 mA-400 mA, +/-1%
DC voltage:
400 mV-4 V-40 V-400 V-1000 V, +/-0.5%
Dimensions:
200x70x70 mm
Display:
3.3/4 Jumbo LCD Display, 3999 Counts
Dual Display:
Yes
Frequency:
40-400-4k-40k-4M Hz
Model:
GT-9510
Overload Protection:
Yes
Power Supply:
1.5 Vx 6A Battery
Resistance:
400-40k-400k-4M-40M ohm, +/-0.8%
Test Insulation:
Resistance at 250 V/500 V/1000 V with range of 0.25 m?-4 G?
Warranty:
1 year Against Manufacturing Defects
Weight:
950 grams
