Auto-ranging:
95-1000 counts
Battery Life:
15 Years Approx
Dimensions:
153x96x200 mm
Display:
999 Counts LCD Display
Insulation Resistance:
1000M of more/DC 1000 V
Operable Altitude:
Less than 2000 m
Operation Circumstances:
Temperature 0-40 Degree C, Humidity <=85%
Over Range Indication:
OL mark appears on insulation resistance range, LO mark appears on voltage's range
Overload Protection:
Insulation resistance : AC 1200 V/10 sec, Voltage: AC 720 V/10 sec
Power Supply:
DC 12 V (8x1.5 V LR14 Battery)
Sample rate:
0.5-10 times/sec
Storage Circumstances:
Temperature -20 to 60 Degree C, Humidity <=90%
Voltage Resistance:
AC 8320 (50/60 Hz)/5 sec
Warranty:
1 year Against Manufacturing Defects
