The FYH - 100 mm, Pillow Block Bearing has a solid cast-iron structure to carry heavy loads during continuous industrial machining operations. It is a heavy device which requires expert handling to avoid any accident. The 100 mm, Pillow Block Bearing has double set screws at the inner steel ring for maximum holding capacity and reliability. The self-contained bearing of the Pillow Block Bearing has sufficient lubrication to perform a smooth operation. In addition, the good colour painted finish of the Block Bearing protects from rust and corrosion.
Product Specifications:
Brand: FYH
Model: UCT 320
Country of origin: China
Product: Pillow Block Bearing
Bore Diameter: 100 mm
Housing Material: Cast Iron
Bearing Material: Chrome Steel
Total length: 345 mm
Finish: Colour painted
Series: UCT
Shaft axis distance: 89 mm
Weight: 36.3 Kg
Width: 108 mm
Key Features:
High sealing efficiency.
Require careful expert handling.
Compact structure for quick mounting.
Facilitate high-speed operation.
Offer task accuracy in harsh weather conditions.
