The FYH - 40 mm, Pillow Block Bearing has a robust cast iron housing to sustain heavy pressure applied during heavy-duty machining. It is applicable where the central part of the main shaft requires free alignment. The 40 mm, Pillow Block Bearing has a slotted housing for proper positioning during the mounting process. It is adequately finished to prevent damages caused by harsh weather conditions like rust, corrosion, and pitting. The Pillow Block Bearing has a pre-lubricated enclosed bearing unit for easy installation and immediate operation. In addition, the self-contained bearing unit of this Block Bearing offers an easy replacement facility.
Product Specifications:
Brand: FYH
Model: UCT 308
Country of origin: China
Product: Pillow Block Bearing
Bore Diameter: 40 mm
Housing Material: Cast Iron
Bearing Material: Chrome Steel
Total length: 162 mm
Finish: Colour painted
Series: UCT
Shaft axis distance: 124 mm
Weight: 4 Kg
Width: 52 mm
Key Features:
Grease nipple for refilling lubricant.
Free movement of the bearing set.
Double sealed, self-contained bearing.
Efficiently sustain radial and thrust load.
