The FYH - 35 mm, Pillow Block Bearing is a premium quality device suitable for multiple heavy-duty industrial tasks. It has two heat-treated steel rings, and the inner ring is fixed to the shaft to prevent relative movement between them. The 35 mm, Pillow Block Bearing has adequate lubrication at a single row deep groove raceway for smooth operation. The lubrication also compensates for minor misalignment during the mounting process. The Pillow Block Bearing has a sealed bearing unit that prevents grease leakage and entry of any foreign particle. In addition, this Block Bearing has one set screw at the inner ring for firm locking and reliability during continuous machining.
Product Specifications:
Brand: FYH
Model: UCHA 206
Country of origin: China
Product: Pillow Block Bearing
Bore Diameter: 35 mm
Bearing Material: Stainless Steel
Total length: 90 mm
Finish: Chrome plated
Series: UCHA
Shaft axis distance: 70 mm
Weight: 0.83 Kg
Width: 42.9 mm
Key Features:
Easy locking of the shaft.
Adequate lubrication for smooth operation.
Hardened structure for increased durability.
Interchangeable bearing and housing.
