Accuracy:
400.0 A: 2 % ± 5 digits (10 Hz to 100 Hz), 2.5 % ± 5 digits (100 Hz to 500 Hz)
Battery type and life:
2 AA, NEDA 15 A, IEC LR6 / 400 hours
Crest Factor:
3 at 500 A, 2.5 at 600 A, 1.42 at 1000 A, add 2 % for C.F. > 2 (50Hz/60Hz)
Ingress Protection rating:
IP30
Inrush:
Max displayed reading: 999.9A
LCD with Backlight:
3½ digits
Log rate/interval:
1 sec minimum/adjustable by PC or FC App
Memory:
Record up to 65,000 readings
Range:
0.5 A to 400.0 A AC
Safety compliance:
IEC 61010-1, 600 V CAT III, 3rd edition Pollution Degree 2
Safety rating:
CAT III 600 V
Size:
20.3cmx7.49cmx3.55 cm
