Buy Crompton 4CSSF3-1525 - 100 mm 3PH 4CSS Series Stainless Steel Pumpset Online

Crompton 4CSSF3-1525 - 100 mm 3PH 4CSS Series Stainless Steel Pumpset


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Crompton 4CSSF3-1525 - 100 mm 3PH 4CSS Series Stainless Steel Pumpset

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Salient Features for Pump:

  • All pump parts- Stainless steel
  • Abrasion and corrosion-resistant construction
  • Upto 40% higher efficiency  than nominal efficiency declared by BIS
  • Lower suction housing- precision-cast stainless steel
  • Hexagonal pump shaft- higher strength against radial load
  • Stainless steel non-retun value to prevent any back flow of water and alleviate any water hammer to the pump, thus safeguarding impellers and diffusers
  • Octagonal bearings and sand flush channels remove particles with the pumped water
  • In-built strainer prevents entry of any particles along with water at suction end
  • Excellent aesthetics

Salient Features of Motor:

  • Suitable in wide voltage
  • Stampings are used of high quality electric grade for better efficiency
  • Winding wire - High quality insulation
  • Copper rotor
  • Stainless steel shaft
  • Shaft & bushes - Mirror finish surface
  • Very low maintanance due to high quality cabon v/s steel combination of thrust bearing
  • All rotating parts- Dynamically balanced
  • Higher efficiency

Applications:

  • Irrigation and drip irrigation
  • Sprinkler, gardening, nursery and bungalows


Crompton offers Stainless Steel Submersible Pumpsets for 100mm borewell. These pumps are having higher wear resistance hence minimize wear and peovides maximum life and optimum performance.

Product Specifications

GENERAL

Brand:
Crompton
Country of Origin:
India
Manufacturer Details:
Crompton, Crompton Greaves Consumer Electrical limited: Equinox Business park, Tower 3,LBS marg, Kurla, Mumbai- 400070, Ph no: 1800 419 0505
Model:
4CSSF3-1525
Motor:
Squirrel cage water filled electric motor for 220 Volts for 1PH and 415 Volts for 3 PH, 50 Hz, AC Supply
No. of Stage:
25
Outlet Size:
32 mm
Packer Details:
Crompton, Crompton Greaves Consumer Electrical limited: Equinox Business park, Tower 3,LBS marg, Kurla, Mumbai- 400070, Ph no: 1800 419 0505
Power:
1.10 KW, 1.50 HP
Speed:
3000 (Syn.)
Total Head vs Discharge at 220/415 volts, 1/3 PH, 50 Hz AC Supply:
138 M: 13 LPM, 125 M: 25 LPM, 113 M: 34 LPM, 100 M: 42 LPM, 75 M: 51 LPM, 50 M: 59 LPM, 25 M: 64 LPM
Voltage Band:
180 to 240 volts for 1PH & 350 to 440 volts for 3 PH
