Electric Motor:
TEFC, 2 Pole (3000 RPM Syn. Speed) Electric motor for single phase, 50 Hz AC Supply at ambient temp. upto 50 Degree Centigrade
Manufacturer Details:
Crompton, Crompton Greaves Consumer Electrical limited: Equinox Business park, Tower 3,LBS marg, Kurla, Mumbai- 400070, Ph no: 1800 419 0505
Motor Protection Class:
IP 44
No. of Bathrooms Recommended:
5
OpeModel Temperature:
Suitable upto 65ç water
Packer Details:
Crompton, Crompton Greaves Consumer Electrical limited: Equinox Business park, Tower 3,LBS marg, Kurla, Mumbai- 400070, Ph no: 1800 419 0505
Pipe Size Suc X Del (mm):
40 X 40
Pressure Setting:
1.5-3.5 bar
Total Head vs Discharge at 220 volts, 1PH, 50 Hz AC Supply:
37 M: 5000 LPH, 36 M: 6000 LPH, 34 M: 7000 LPH, 32 M: 8000 LPH, 29 M: 9000 LPH, 25 M: 10000 LPH, 21 M: 11000 LPH
Voltage Band:
180 to 240 volts
