Electric Motor:
TEFC, 2 Pole (3000 RPM Syn. Speed) Electric motor for single phase, 50 Hz AC Supply at ambient temp. upto 50 Degree Centigrade
Manufacturer Details:
Crompton, Crompton Greaves Consumer Electrical limited: Equinox Business park, Tower 3,LBS marg, Kurla, Mumbai- 400070, Ph no: 1800 419 0505
Motor Protection Class:
IP 44
No. of Bathrooms Recommended:
5
Operating Temperature Range:
Suitable upto 65ç water
Packer Details:
Crompton, Crompton Greaves Consumer Electrical limited: Equinox Business park, Tower 3,LBS marg, Kurla, Mumbai- 400070, Ph no: 1800 419 0505
Pipe Size Suc X Del (mm):
32 X 25
Pressure Setting:
1.5-5.0 bar
Total Head vs Discharge at 220 volts, 1PH, 50 Hz AC Supply:
53 M: 1000 LPH, 50 M: 2000 LPH, 47 M: 3000 LPH, 44 M: 4000 LPH, 38 M: 5000 LPH, 29 M: 6000 LPH, 20 M: 7000 LPH
Voltage Band:
180 to 240 volts
