Area of Application:
Recommended for welding Steels, HSS, Aluminium, CrNi materials, Coated Plates
Connection Cable:
4?10 mm?
Dimensions (LxBxH) (without wire drive unit):
1226?630?741 mm
Dimensions (LxBxH) of compact machine:
1226?630?942 mm
Mains Voltage:
400V/50Hz/3-phase
Maximum Track Width:
approx.552 mm
Open Circuit Voltage:
88V
Special Voltages:
380V, 415V, 440V, 480V, 500V
Weight (without wire drive):
244 Kg
Weight Compact Machine:
246 Kg
Weld Current at 100% Duty Cycle:
500A/39V
Weld Current at 60% Duty Cycle:
600A/44V
