Area of Application:
Recommended for welding Steels, HSS, Aluminium, CrNi materials, Coated Plates
Connection Cable:
4?6 mm?
Dimensions (LxBxH) (without wire drive unit):
1226?630?741 mm
Dimensions (LxBxH) of compact machine:
1226?630?942 mm
Mains Voltage:
400V/50Hz/3-phase
Maximum Track Width:
approx.552 mm
Open Circuit Voltage:
75V
Special Voltages:
380V, 415V, 440V, 480V, 500V
Weight (without wire drive):
204 Kg
Weight Compact Machine:
206 Kg
Weld Current at 100% Duty Cycle:
350A/31,5V
Weld Current at 60% Duty Cycle:
450A/36,5V
