Baker - Zenith 3 CNC Co Ordinate Measuring Machine


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Baker - Zenith 3 CNC Co Ordinate Measuring Machine

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Greater air bearing separation results in greater stiffness, and so has improved the accuracy significantly. The first term error for this new model is more than a micron better than the Zenith too. And all this comes with no cost penalty: The Zenith 3 CMM will continue to be sold at the same hugely competitive price that its predecessor was famed for, making large scale CMM measurements not only simple, but affordable.

Features:

  • Smallest overall footprint of any comparable size CMM
  • Choice of Y axis sizes ranging from 1000mm to 3000mm
  • Suitable for the workshop environment
  • Protection from environmental vibrations as standard
  • Optimised friction free air bearings, all aluminium bridge and granite table
  • CMM Touch Screen Joystick supplied as standard
  • Free stylus change rack with every motorised probe head upgrade
Product Specifications

GENERAL

Accessories:
Automatic Temperature Compensation, CCD Camera System, Collimated Back Light Option
Air consumption:
50 l/min (1.8 cfm)
Axis Travel:
X - 1000 mm, Y - 1000, 1500, 2000, 2500, 3000 mm, Z - 600, 800 mm
Brand:
Baker
Manufacturer Details:
Baker Gauges Pvt Ltd,33-1-2, Nagar Road, Pune-411014, India, Phone : 91-20-66093800
Max Acceleration Vector:
600 mm/sec²
Max Velocity Vector:
600 mm/sec
Operational Temperature Range:
0 - 45 deg C
Optimum Temperature Range:
18 - 22 deg C
Overall Size:
X - 1520 mm, Y - 1700, 2200, 2700, 3200, 3700 mm, Z - 2500, 2900 mm
Packer Details:
Baker Gauges Pvt Ltd,33-1-2, Nagar Road, Pune-411014, India, Phone : 91-20-66093800
Product:
Zenith 3 CNC Co Ordinate Measuring Machine
Scale Resolution:
0.5 ?m
Table Load Capacity:
1500 kg
Table Type:
Solid Granite
Volumetric Accuracy:
TP20 (2.7 + 0.4L/100) µm, TP200 (2.6 + 0.4L/100) µm, SP25M (2.4 + 0.4L/100) µm
