Description

The Xtreme is a self-contained inspection unit. It has no air bearings, so no requirement for compressed air just plug it in and go. Built-in temperature control and a compact footprint allow the Xtreme to be placed wherever it is needed.

Another unique advantage of the Xtreme is that all of the struts are controlled to operate at 40 degC. This means that the measurement structure of the Xtreme will always be at a constant temperature even when the ambient environment is not controlled and hence measurement accuracy will be maintained.The innovative Xtreme is an evolution of CMM technology. However, it is the price of the Xtreme that will have such a significant effect on the market, with the potential for multiple units replacing a single inspection room CMM, ensuring that measurement is provided close to where it is required.

Features:

  • No compressed air required the Xtreme is 'plug and go'
  • The Xtreme's mechanical bearings mean that it is robust, so ideal for less than perfect environments
  • Built-in temperature control - accuracy is maintained even when ambient temperature is not controlled.
  • Aberlink's revolutionary easy-to-use measurement software
  • Shortest learning curve of any equivalent system - 1 day without prior CMM experience.
  • Smallest overall footprint of any comparable size CMM
Product Specifications

GENERAL

Axis Travel:
X - 300 mm, Y - 300 mm, Z - 200 mm
Brand:
Baker
Manufacturer Details:
Baker Gauges Pvt Ltd,33-1-2, Nagar Road, Pune-411014, India, Phone : 91-20-66093800
Max Acceleration Vector:
750 mm/sec²
Max Velocity Vector:
750 mm/sec
Operational Temperature Range:
0 - 45 degree C
Overall Size:
X - 770 mm, Y - 860 mm, Z - 2025 mm (when on bench)
Packer Details:
Baker Gauges Pvt Ltd,33-1-2, Nagar Road, Pune-411014, India, Phone : 91-20-66093800
Product:
Xtreme CNC Co Ordinate Measuring Machine
Scale Resolution:
0.5 ?m
Table Type:
Solid granite plate
Volumetric Accuracy:
3 µm + L/250 mm
