Baker - Azimuth CNC Co Ordinate Measuring Machine


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081
Baker

Baker - Azimuth CNC Co Ordinate Measuring Machine

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

The revolutionary bridge of the Azimuth incorporates aluminium honeycomb sheets developed for use in formula one and the aerospace industry. The remarkable stiffness to weight ratio that this provides gives the Azimuth an edge in both performance and speed. For a machine of this size, the Azimuth is not only fast, but extremely accurate.

The drive systems designed for the Azimuth offer simplicity and reliability and the novel system used on the Y axis ensures that there is no degradation of performance across the full range of machine sizes offered up to 3m. A big machine should also be able to measure a heavy component and this is another area where Aberlink have applied innovative thinking. Rather than simply increasing the depth of the granite table, which adds huge cost and weight to the machine, we offer a specially designed load plate to sit on the granite base. This plate can accept up to a six tonne load which will then be transmitted directly through the feet of the machine bench directly to the floor, meaning no loss of metrology performance whatsoever - just another really clever idea.

Features:

  • Capable of measuring parts up to 6000kg in weight
  • Fitted with 0.0001mm linear encoders for superior accuracy
  • Unique self-contained drive system ensures excellent performance over the entire measuring volume
  • Anti-vibration mounts as standard
  • Choice of Y axis sizes ranging from 1000mm to 3000mm Rapid, High Accuracy Large Volume CMM
Product Specifications

GENERAL

Accessories:
Automatic Temperature Compensation, CCD Camera System, Collimated Back Light Option, Load plate for loads up to 6 tonnes
Air consumption:
50 l/min (1.8 cfm)
Axis Travel:
X - 1200 mm, Y - 1000, 1500, 2000, 2500, 3000 mm, Z - 1000 mm
Brand:
Baker
Manufacturer Details:
Baker Gauges Pvt Ltd,33-1-2, Nagar Road, Pune-411014, India, Phone : 91-20-66093800
Max Acceleration Vector:
1700 mm/sec²
Max Velocity Vector:
1300 mm/sec
Operational Temperature Range:
0 - 45 deg C
Optimum Temperature Range:
18 - 22 deg C
Overall Size:
X - 1850 mm, Y - 2000, 2500, 3000, 3500, 4000 mm, Z - 2320 mm
Packer Details:
Baker Gauges Pvt Ltd,33-1-2, Nagar Road, Pune-411014, India, Phone : 91-20-66093800
Product:
Azimuth CNC Co Ordinate Measuring Machine
Scale Resolution:
0.1 ?m
Table Load Capacity:
500 kg
Table Type:
Granite
Volumetric Accuracy:
TP20 (2.9 + 0.4L/100) ?m, TP200 (2.8 + 0.4L/100) ?m, SP25M (2.6 + 0.4L/100) ?m
